Belltech 2019+ RAM 1500 (6-lug) lowers the front of your vehicle 3 to 4 inches and the rear 4 to 5 inches. The front suspension includes Belltech lowering coilovers using high-quality, multi-functional components built to last. Each coilover includes a finely tuned Belltech damper with a large damper body and 35mm independent rebound and compression valves. Both the main spring and helper spring are made of cold-formed tensile steel and are powdercoated to prevent rust and wear. The coilovers use a progressive rate polymer and open-cell bump stop for ideal bump stop engagement with OE top mounts. Spindles are included to complete the frontend lowering another 2 inches by bringing your wheels’ mounting higher and settling your vehicle closer to the ground.

Combining newly released height-adjustable front coilovers with time-tested lowering components equals optimum sport truck handling, all in one convenient package.

The rearend of the vehicle showcases Belltech Street Performance shocks. They sport large 2.2-inch (55mm) damper bodies and use 35mm independent rebound and compression valves. To achieve 4 or 5 inches in lowering, replacement coil springs and 1-inch spacers are included. To gain additional lowering for a full 5 inches, the spacer is removed. To preserve correct anti-sway bar angles, the kit includes an adjustable end link assembly. A 1 3/8-inch-diameter solid front sway bar and 13/16-inch-diameter hollow rear sway bar that is made of cold-formed steel is also included.

Other kits with varying lowering ranges for the 2019+ Ram (6-lug) are also available on

Belltech also created a roll center correction bracket that keeps the axle centered under the vehicle to maintain proper suspension geometry.
